Welded Mesh Fencing is an elegant and robust fencing solution designed for a variety of applications. With its symmetrical circular arc design and reinforced grooves on both the front and rear panels, this fence provides a visually appealing and consistent appearance inside and outside the factory boundary.
Material and Design
The fence is constructed using high-strength aluminum-magnesium alloy profiles, offering exceptional corrosion resistance and durability. The use of international advanced nano-ceramic and electrostatic powder coating technology ensures a smooth and delicate surface, with a ten-year anti-corrosion warranty.
Connection and Anti-Theft Features
Posts and grids are connected with special fittings and stainless steel anti-theft bolts, providing strong anti-theft performance. This robust connection system enhances the security and longevity of the fence.
Specifications and Dimensions
- Post Thickness: Available in two thicknesses: ordinary (1.5 mm) and reinforced (2.0 mm).
- Post Dimensions: 75 mm x 100 mm.
- Mesh Options:
- Monofilament Bending Mesh: Light 545 triple wire mesh, suitable for general protection.
- Medium 656 Wire Mesh: Dense mesh fencing pieces, suitable for high-security areas.
Features and Benefits
- Visual Appeal: Symmetrical circular arc shape design with reinforced grooves for a consistent look.
- Durability: High-strength aluminum-magnesium alloy profile for a long service life.
- Corrosion Resistance: Advanced coating technology provides a smooth finish and ten-year anti-corrosion warranty.
- Anti-Theft: Special fittings and stainless steel anti-theft bolts ensure strong security.
- Versatility: Suitable for a range of applications from general protection to high-security areas.
Common Applications
Welded Mesh Fencing is suitable for various applications, including:
- Factory Boundaries: Ensures consistent visual appeal inside and outside the factory.
- General Protection Places: Ordinary columns with monofilament bending mesh provide sufficient security.
- High Security Areas: Reinforced columns with dense medium 656 wire mesh offer enhanced protection.
- Commercial Properties: Adds an aesthetic and secure boundary.
- Residential Areas: Provides a durable and visually appealing fence.
Welded Mesh Fencing combines durability, security, and aesthetic appeal, making it an ideal choice for a wide range of fencing needs.
Double Wire Panel
| Wire(mm) | Mesh(mm) | Width of Panel(mm) | Height of Panel(mm) | Post Section Size (mm) | Distance between Posts (mm) | Post Height (mm) |
| 6/5/6 | 50*200 | 2500 | 1420 | 95*65*1.5 | 2523 | 1900 |
| 1620 | 2100 | |||||
| 1820 | 2300 | |||||
| 2020 | 2500 | |||||
| 2220 | 2800 | |||||
| 2420 | 3000 |
Single Wire Panel
| Wire(mm) | Mesh(mm) | Width of Panel(mm) | Height of Panel(mm) | Post Section Size (mm) | Distance between Posts (mm) | Post Height (mm) | |
| Width of panel 2475(4/5) | Width of panel 2970(4/5) | ||||||
| 4/4 5/5 | 55*200 | 2475 / 2970 | 1420 | 95*65*1.5 | 2497 / 2498 | 2992 / 2993 | 1900 |
| 1620 | 2100 | ||||||
| 1820 | 2300 | ||||||
| 2020 | 2500 | ||||||
| 2220 | 2800 | ||||||
| 2420 | 3000 | ||||||
| 4/4 5/5 | 65*200 | 2470 / 2990 | 1420 | 95*65*1.5 | 2492 / 2493 | 3012 / 3013 | 1900 |
| 1620 | 2100 | ||||||
| 1820 | 2300 | ||||||
| 2020 | 2500 | ||||||
| 2220 | 2800 | ||||||
| 2420 | 3000 | ||||||
